Service Portfolio
Certified to ISO 9001:2015
Machining
Turning
- Lot size: min. 100, max. 50,000
- Workpiece dimensions: Diameter min. 25 mm, max. 350 mm; Length min. 5 mm, max. 400 mm
Automatic Turning (Bar Stock)
- Lot size: min. 100, max. 50,000
- Workpiece dimensions: Diameter min. 25 mm, max. 100 mm; Length min. 5 mm, max. 400 mm
Shaft Machining – Turning
- Lot size: min. 100, max. 50,000
- Workpiece dimensions: Diameter min. 25 mm, max. 250 mm; Length min. 40 mm, max. 800 mm
- Weight: max. 40 kg
Hard Turning
- Lot size: min. 100, max. 50,000
- Workpiece dimensions: Diameter min. 25 mm, max. 300 mm; Length min. 5 mm, max. 200 mm
Complete Machining: Turning with Milling
- Lot size: min. 100, max. 50,000
- Workpiece dimensions: Diameter min. 25 mm, max. 400 mm; Length min. 5 mm, max. 800 mm
Gear Milling
- Lot size: min. 100, max. 50,000
- External / involute gearing (up to module 5), as well as face / Hirth gearing
- Weight: max. 40 kg
Fine Machining
External Cylindrical Grinding
- Lot size: min. 100 – max. 50,000
- Workpiece dimensions: Diameter min. 5 mm – max. 400 mm, length min. 10 mm – max. 700 mm
- Weight: max. 40 kg
Internal Cylindrical Grinding
- Lot size: min. 100 – max. 50,000
- Workpiece dimensions: Diameter min. 6 mm – max. 150 mm, length min. 5 mm – max. 150 mm
Surface Grinding
- Lot size: min. 100 – max. 50,000
- Workpiece dimensions: Width min. 5 mm – max. 250 mm, height min. 0.5 mm – max. 200 mm, length min. 5 mm – max. 500 mm
- Weight: max. 40 kg
Mechanical assembly of components
- Lot size: min. 100 – max. 50,000
- Workpiece dimensions: 20 × 300 mm
- Weight: max. 20 kg
Laser Marking
- Surface marking of parts with text, logos, serial numbers, or graphics (Data Matrix™, QR codes, barcodes)
- Marking area: 110 × 110 mm
Surface Treatment
Heat treatment or surface finishing is carried out at partner companies certified according to TS 16949 or ISO 9001, with which quality assurance agreements are in place.
Parts Handling
Cleaning, as well as customer-specific packing in lattice boxes, cartons, or KLTs.
